The iDOME is Portable Dependable Comforting Safe Weight-Bearing Easy to Set Up

DONATE TODAY

Darren Madrigal, Founder iDOME Shelters

Our Mission

To provide safe, durable portable shelter systems for humanitarian and disaster reliefs.

The iDOME is...

PORTABLE
The iDOME frame easily packs into a portable one-person carry bag.

DEPENDABLE

Our patented frame design is weight-bearing and can withstand winds up to 65 mph.

DURABLE

Built with steel, aluminum, carbon fiber parts and weatherproof materials,
the iDOME Shelter is extremely durable

COMFORTING

The size and shape of the iDOME Shelter is designed to
lower stress and provide comfort.

SAFE

Because we use durable dependable materials, you can feel safe inside
the iDOME Shelter.

WEIGHT-BEARING

The iDOME Shelter holds up to 1000 lbs of weight.
Based on the principles of Tensegrity – The more weight you put on then frame,
the more stable the frame becomes.

EASY TO SETUP

Our patented frame is fully connected, there are no parts to assemble, and it sets up
in minutes.

“They are the best emergency
shelters out there. Period.”

As a first responder I have spent the last 13 years responding to every type of natural disaster. During (and certainly after) the initial search and rescue phase one of the first orders of business is to establish emergency shelters for IDP’s (internally displaced person). Because of this, I have personal hands-on experience with virtually every shelter on the market. It is my conclusion that the iDOME Shelter not only provides the optimum strength and sturdiness to withstand such chaotic environments, but also a much needed sanctuary for those who inhabit them (IDP’s and first responders, alike). They are the best emergency shelters out there. Period.

– Jon Rose, Founder for Waves 4 Water

“Global Empowerment Mission is
proud to partner with iDome.”

“Global Empowerment Mission is proud to partner with iDome. In the last few years, GEM has received donated iDomes that we distributed after various disasters across our globe. These aren’t just tents, these can serve as good temporary housing for many. The feedback we received from recipients are excellent.

The climate and man made refugee crisis is at an all time high and growing. According to the United Nations, 89.3 million people were displaced last year alone due to the result of persecution, conflict, violence, human rights violations or events seriously disturbing public order.

We encourage governments, foundations, NGO’s and the supporting public to help fund the manufacturing costs on these shelters so that they can be distributed to those in need on a large scale.”

-Michael Capponi, Founder GEM

FEATURES

PATENTED TECHNOLOGY
U.S. PATENT NO. 7,533,681 | U.S. PATENT NO. 7,900,646

• GEODESIC DOME DESIGN


• NO PARTS TO ASSEMBLE


• SETS UP IN MINUTES


• HOLDS 2 HAMMOCKS


• HOLDS GEAR/SUPPLIES OFF GROUND


• WEATHERPROOF COVERS


• CEILING PEAK HEIGHT 8 FT


• FLOOR SPACE 91 SQ FT


• INTERIOR SPACE 527 CU FT


• HOLDS 1000 LBS

FEATURES

PATENTED TECHNOLOGY
U.S. PATENT NO. 7,533,681 | U.S. PATENT NO. 7,900,646

• GEODESIC DOME DESIGN


• NO PARTS TO ASSEMBLE


• SETS UP IN MINUTES


• HOLDS 2 HAMMOCKS


• HOLDS GEAR/SUPPLIES OFF GROUND


• WEATHERPROOF COVERS


• CEILING PEAK HEIGHT 8 FT


• FLOOR SPACE 91 SQ FT


• INTERIOR SPACE 527 CU FT


• HOLDS 1000 LBS

THE IDOME RESCUE SYSTEM SPECS

• ALUMINUM FRAME TUBES:
6.5 FT X 1 IN X 0.063 IN

• STAR JOINT:
POWDER COATED 11 GAUGE STEEL

• V-CLEAT BY RONSTAN:
CARBON FIBER ANCHOR SYSTEM

• POWER CABLE:
NYLON COATED STEEL ROPE, 7 X 19 STRAND
CORE.

• ANCHOR ROPES:
1/4 IN /0.65 CM. TENSILE STRENGTH,
1,650LBS/749KG

• FRAME WEIGHT:
41 LB / 18.6 KG
• FRAME HOLDS:
1000 LBS / 454 KGS

• WEIGHT OF COVERS:
33 LB / 15 KG

• SIDE WALLS:
3000PU 600D POLY

• FLOOR:
HEAVY DUTY PVC FLOOR

• MESH ROOF TOP:
NO-SEE-UMS MESH, 600D POLY 3000PU FACIA
W/ VELCRO & TURN BUTTONS

• RAIN FLY/CANOPY TOP:
600D POLY 3000PU, NYLON STRAPS
W/CARABINER CLIPS

• FRONT DOOR HEIGHT:
5.3 FT / 1.5 M
• PEAK HEIGHT:
8 FT / 2.4 M

• FLOOR DIAMETER:
11 FT / 3.35 M

• FLOOR SPACE:
91 SQ FT / 8.45 SQ MÇ

• INTERIOR SPACE:
527 CU FT / 15 CU M

• STEEL TENT STAKES (4):
18 IN TALL X 1/2 IN THICK /
45 CM TALL X 1.27 CM THICK

• BONUS BLUE CANOPY TOP:
WEATHERPROOF 260 G POLY COTTON RIPSTOP

• FRAME BAG:
DURABLE PVC BAG W/ PADDED STRAPS &
RUBBER HANDLES
